[Smart BMS] This LiFePO4 Battery has a built-in 4S 100A intelligent BMS with overcharge protection, over-discharge protection, overcurrent protection, short-circuit protection, cell balancing, etc. It has a 1200W output power and a 100A continuous discharge current.
[Remote Monitoring] The Battery has a built-in Bluetooth module, which can be connected to Bluetooth via a mobile phone APP to monitor the battery status.
[IP65] The battery package is coated with waterproof glue to achieve IP65 level dust and water resistance, which is better for outdoor scenes such as trolling motors and electric boats.
[Low Temperature Protection] The battery is equipped with a low temperature protection function to effectively protect the battery from damage.
[5000 Times Deep Cycles] The battery uses A-grade new lifepo4 cells. After 5000 deep cycles, the battery health (SOH ≥ 80%)
[4S4P Extended Energy Storage System] The battery module supports a 4S4P structure, suitable for 48V systems, and achieves 20.48KWh of energy storage.
Wistek 12V 100Ah Max LiFePO4 Lithium Deep Cycle Battery adopts 1C rate EVE Grade A cells.
It contains no toxins and can charge over 5000 times at 100% DOD for over a 10-year lifespan. Withstanding Max 1280W Power and can support a maximum 1C rate discharging and 1C rate charging, it can be used in scenarios that require higher Power.
No need to bother with the limitations of lead-acid batteries anymore! Choose Wistek without hesitation for its lighter weight, less space, higher power, and larger energy!

As a group 31 size battery with 1280Wh capacity, the 12V 100Ah Max LiFePO4 battery supports up to 1280W of power delivery. This high-power performance makes it well-equipped to fuel energy-intensive applications. Whether traveling with RVs, fishing with trolling motors, or maintaining higher Power loads at home and off-grid, this high-output LiFePO4 battery answers with enduring strength and stable performance.

Equipping a high-performance 100A BMS, the Wistek 12V 100Ah Max lithium ion deep cycle battery allows for running more energy-intensive appliances with stable, unaffected power and supports over-charging, over-discharging, over-current, over-temperature and short-circuit protections to keep users and the battery itself safeguarded from harm.
Wistek 12V 100Ah Max lithium battery has a 100A Continuous discharge/100A Continuous charge current and 300A/1S peak discharge Current. No compromises need to be made on Load Power. With its top quality & performance, this battery as a robust workhorse is ready to handle whatever appliances you power with it.




| Product Model | LM12100 |
| Nominal Capacity | 100Ah/1280Wh |
| Operating Voltage Range | 10V-14.6V |
| Nominal Voltage |
12.8V |
| Number Of Cycles |
5000 Cycles(@80%SOH) |
| Charging Characteristics |
CCCV/IU |
| Peak Discharge Current | 350A |
| Charging Voltage | 14.6V |
| Recommended Charge Current | 20A |
| Maximum Charge Current | 100A |
| Maximum Discharge Current | 100A |
| Peak Discharge Cut-Off Current (5 ~15 ms) | 300A |
| BMS Battery Management System | Intergrated |
| Monitoring | Bluetooth APP |
| Application/ Interconnection | Series and parallel connection for 12V,24V,36V,48V applications. |
| Protection | IP65 |
| Temperature Range(discharge) | -20~55℃ |
| Temperature Range(charge) | 0~55℃ |
| Temperature Range(storage) | -20~55℃ |
| Connection Screw | M8 |
| Warranty | 5 Years Warranty |
| Weight | 11±0.5kg |
|
Dimension(W*T*H) in mm |
330*170*220mm |
